威尔逊奥林匹亚珀金斯配件T401716


详细描述:

威尔逊奥林匹亚珀金斯配件T401716 燃油过滤器座

项序 零配件号码 最近的零配件号码  描述

1 T401716 1 T401716 燃油过滤器座

4 CH12612 2 CH12612 螺拴

5 CH11819 2 CH11819 垫圈

6 CH10836 1 CH10836 阀

7 T400188 1 T400188 密封垫O形圈

8 T400684 1 T400684 密封垫O形圈

9 CH10439 1 CH10439 手油泵

10 CH10008 1 CH10008 密封垫

11 CH10246 1 CH10246 螺拴

12 CH10086 1 CH10086 垫圈

13 CH11565 1 CH11565 螺拴

14 T401636 1 T401636 垫圈

15 T408416 1 T408416 密封垫O形圈

16 T407241 1 T407241 连接器

17 CH11880 1 CH11880 密封垫O形圈

18 T409325 1 T409325 帽

19 T400857 1 T400857 密封垫O形圈

20 T400695 1 T400695 密封垫O形圈

21 T400694 1 T400694 堵塞

22 T401715 1 T401715 托架

23 T400188 1 T400188 密封垫O形圈

24 CH12017 1 CH12017 非回路阀

28 CH11819 2 CH11819 垫圈

29 ST43558 2 ST43558I 螺拴

30 CH10287 1 CH10287 堵塞

31 T406205 1 T406205 密封垫O形圈

32 CH10287 1 CH10287 堵塞

33 T406205 1 T406205 密封垫O形圈

Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment

1 T401716 1 T401716 FUEL FILTER HEAD

4 CH12612 2 CH12612 BOLT

5 CH11819 2 CH11819 WASHER

6 CH10836 1 CH10836 VALVE

7 T400188 1 T400188 SEAL - O RING

8 T400684 1 T400684 SEAL - O RING

9 CH10439 1 CH10439 PRIMING PUMP

10 CH10008 1 CH10008 GASKET

11 CH10246 1 CH10246 BOLT

12 CH10086 1 CH10086 WASHER

13 CH11565 1 CH11565 BOLT

14 T401636 1 T401636 WASHER

15 T408416 1 T408416 SEAL - O RING

16 T407241 1 T407241 CONNECTOR

17 CH11880 1 CH11880 SEAL - O RING

18 T409325 1 T409325 CAP

19 T400857 1 T400857 SEAL - O RING

20 T400695 1 T400695 SEAL - O RING

21 T400694 1 T400694 PLUG

22 T401715 1 T401715 BRACKET

23 T400188 1 T400188 SEAL - O RING

24 CH12017 1 CH12017 NON RETURN VALVE

28 CH11819 2 CH11819 WASHER

29 ST43558 2 ST43558I BOLT

30 CH10287 1 CH10287 PLUG

31 T406205 1 T406205 SEAL - O RING

32 CH10287 1 CH10287 PLUG

33 T406205 1 T406205 SEAL - O RING

项序 零配件号码 最近的零配件号码  描述

1 T401702 1 T401702 水管

2 T401708 1 T401708 承接器

3 CH11880 1 CH11880 密封垫O形圈

4 CH11880 1 CH11880 密封垫O形圈

5 CH11410 1 CH11410 堵塞

6 CH11880 1 CH11880 密封垫O形圈

7 CH11411 1 CH11411 灰尘盾

8 T401711 1 T401711 承接器

9 T406205 1 T406205 密封垫O形圈

10 CH10286 1 CH10286 堵塞

11 CH11880 1 CH11880 密封垫O形圈

12 T401717 1 T401717 管

13 T401704 1 T401704 承接器

14 T400646 1 T400646 承接器

15 CH11880 1 CH11880 密封垫O形圈

16 T401703 1 T401703 管夹

17 CH11819 1 CH11819 垫圈

18 CH11807 1 CH11807 螺拴

19 T401448 1 T401448 间隔器

20 T401714 1 T401714 水管

21 CH11595 1 CH11595 连接器

22 T406205 1 T406205 密封垫O形圈

23 CH10841 1 CH10841 连接

24 CH11880 1 CH11880 密封垫O形圈

25 T401448 1 T401448 间隔器

26 T400658 1 T400658 托架

27 T400659 1 T400659 托架

28 CH11819 1 CH11819 垫圈

29 CH11807 1 CH11807 螺拴

30 T400660 1 T400660 衬套

31 T401714 1 T401714 水管

32 CH10026 1 CH10026 连接

33 CH11880 1 CH11880 密封垫O形圈

34 CH10026 1 CH10026 连接

35 CH11880 1 CH11880 密封垫O形圈

36 T401713 1 T401713 肘管

37 CH10133 1 CH10133 密封垫O形圈

38 CH11865 1 CH11865 螺帽

39 CH11819 1 CH11819 垫圈

40 T400659 1 T400659 托架

41 T400660 1 T400660 衬套

42 T400658 1 T400658 托架

43 T401705 1 T401705 螺拴

44 CH10255 1 CH10255 垫圈

45 T400659 1 T400659 托架

46 T400660 1 T400660 衬套

47 T400658 1 T400658 托架

48 T401712 1 T401712 间隔器

49 T400658 1 T400658 托架

50 T400660 1 T400660 衬套

51 T400659 1 T400659 托架

52 T401707 1 T401707 间隔器

53 T401720 1 T401720 杆

54 T401706 1 T401706 间隔器

55 CH10054 2 CH10054

Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment

1 T401702 1 T401702 HOSE

2 T401708 1 T401708 ADAPTOR

3 CH11880 1 CH11880 SEAL - O RING

4 CH11880 1 CH11880 SEAL - O RING

5 CH11410 1 CH11410 PLUG

6 CH11880 1 CH11880 SEAL - O RING

7 CH11411 1 CH11411 DUST SHIELD

8 T401711 1 T401711 ADAPTOR

9 T406205 1 T406205 SEAL - O RING

10 CH10286 1 CH10286 PLUG

11 CH11880 1 CH11880 SEAL - O RING

12 T401717 1 T401717 PIPE

13 T401704 1 T401704 ADAPTOR

14 T400646 1 T400646 ADAPTOR

15 CH11880 1 CH11880 SEAL - O RING

16 T401703 1 T401703 PIPE CLIP

17 CH11819 1 CH11819 WASHER

18 CH11807 1 CH11807 BOLT

19 T401448 1 T401448 SPACER

20 T401714 1 T401714 HOSE

21 CH11595 1 CH11595 CONNECTOR

22 T406205 1 T406205 SEAL - O RING

23 CH10841 1 CH10841 CONNECTION

24 CH11880 1 CH11880 SEAL - O RING

25 T401448 1 T401448 SPACER

26 T400658 1 T400658 BRACKET

27 T400659 1 T400659 BRACKET

28 CH11819 1 CH11819 WASHER

29 CH11807 1 CH11807 BOLT

30 T400660 1 T400660 BUSH

31 T401714 1 T401714 HOSE

32 CH10026 1 CH10026 CONNECTION

33 CH11880 1 CH11880 SEAL - O RING

34 CH10026 1 CH10026 CONNECTION

35 CH11880 1 CH11880 SEAL - O RING

36 T401713 1 T401713 ELBOW

37 CH10133 1 CH10133 SEAL - O RING

38 CH11865 1 CH11865 NUT

39 CH11819 1 CH11819 WASHER

40 T400659 1 T400659 BRACKET

41 T400660 1 T400660 BUSH

42 T400658 1 T400658 BRACKET

43 T401705 1 T401705 BOLT

44 CH10255 1 CH10255 WASHER

45 T400659 1 T400659 BRACKET

46 T400660 1 T400660 BUSH

47 T400658 1 T400658 BRACKET

48 T401712 1 T401712 SPACER

49 T400658 1 T400658 BRACKET

50 T400660 1 T400660 BUSH

51 T400659 1 T400659 BRACKET

52 T401707 1 T401707 SPACER

53 T401720 1 T401720 ROD

54 T401706 1 T401706 SPACER

55 CH10054 2 CH10054 CABLE TIE

项序 零配件号码 最近的零配件号码  描述

1 T401692 1 T401692 滤油器座

4 CH11299 2 CH11299 螺拴

5 CH11865 2 CH11865 螺帽

6 T401694 2 T401694 螺拴

7 T401001 2 T401001 垫圈

8 T401700 1 T401700 板

9 T401696 1 T401696 承接器

10 T400544 1 T400544 密封垫O形圈

11 CH10822 1 CH10822 工具

12 T409314 1 T409314 密封垫O形圈

13 T401693 1 T401693 承接器

14 T400544 1 T400544 密封垫O形圈

15 2658 A101 1 2658 A101 帽

16 T401697 1 T401697 承接器

17 T400544 1 T400544 密封垫O形圈

18 4587260 1 4587260 滤油器

19 T401695 1 T401695 水管 -油

20 T401698 1 T401698 承接器

21 T400762 1 T400762 密封垫O形圈

22 T401695 1 T401695 水管 -油

23 T401699 1 T401699 承接器

24 T400762 1 T400762 密封垫O形圈

25 T401691 1 T401691 盖

26 T401690 2 T401690 密封垫O形圈

27 T401689 1 T401689 承接器

Item Parts No. Qty. Latest Part No. Description Cut Out Cut In Comment

1 T401692 1 T401692 OIL FILTER HEAD

4 CH11299 2 CH11299 BOLT

5 CH11865 2 CH11865 NUT

6 T401694 2 T401694 BOLT

7 T401001 2 T401001 WASHER

8 T401700 1 T401700 PLATE

9 T401696 1 T401696 ADAPTOR

10 T400544 1 T400544 SEAL - O RING

11 CH10822 1 CH10822 TOOL

12 T409314 1 T409314 SEAL - O RING

13 T401693 1 T401693 ADAPTOR

14 T400544 1 T400544 SEAL - O RING

15 2658A101 1 2658A101 CAP

16 T401697 1 T401697 ADAPTOR

17 T400544 1 T400544 SEAL - O RING

18 4587260 1 4587260 OIL FILTER

19 T401695 1 T401695 HOSE - OIL

20 T401698 1 T401698 ADAPTOR

21 T400762 1 T400762 SEAL - O RING

22 T401695 1 T401695 HOSE - OIL

23 T401699 1 T401699 ADAPTOR

24 T400762 1 T400762 SEAL - O RING

25 T401691 1 T401691 COVER

26 T401690 2 T401690 SEAL - O RING

27 T401689 1 T401689 ADAPTOR
