首页 产品展示>英国珀金斯Perkins柴油发动机2506C-E15TAG原装进口零配件

英国珀金斯Perkins柴油发动机2506C-E15TAG原装进口零配件

珀金斯零配件 珀金斯发动机广泛应用于: ●发电机组(例如:威尔信发电机组) ●工程机械(例如:JCB小型挖掘机、英格索兰山猫小型挖掘机、福格勒摊铺机、美国威猛摊铺机、特雷克斯两头忙) ●叉车(林德、海斯特、永恒力、台励福) ●农业机械(例如:拖拉机、联合收割机) ●其它工业设备(例如:吉尼(GENIE)高空作业车、JLG高空作业车) 2000系列 技术已相当成2000系列升发动机是为应对当今发电行业的严苛要求而专门设计的,该系列发动机尤其适用于备用发电领域。具有优良的电力输出性能及燃油经济性,可靠耐用,燃油耗率低、噪音小、排放低。实现了最佳的动力匹配,可以提供适合各种用途和需求的发电系统。
产品咨询

详细描述

英国珀金斯Perkins柴油发动机2506C-E15TAG1原装进口零配件
BuildList: MGAF5001U
序号 零件名称 零件号 数量(一车付)
1             Fuel Filter CH10931 1
2             Pre-Fule Filter CH10930 1
3             Oil Filter CH10929 1
4             Air Filter  SEV551F/4 1
5             ALTERNATOR BELT CH11202 1
6             FAN BELT CH11950 1
7             SEAL - ROCKER BOX COVER CH11353 1
8             GASKET - CYLINDER HEAD KRP1529 1
9             THERMOSTAT CH11620 2
10         FRONT OIL SEAL CH11379 1
11         SEAL - REAR END OIL CH11304 1
12         Fuel Filter CH10931 1
13         Pre-Fule Filter CH10930 1
14         Oil Filter CH10929 1
15         ALTERNATOR BELT CH11202 1
16         FAN BELT CH11950 1
17         Air Filter  SEV551F/4 1
18         SEAL - ROCKER BOX COVER CH11353 1
19         GASKET - CYLINDER HEAD KRP1529 1
20         PISTON RING KIT KRP3018 6
21         INTAKE  VALVE CH11021 12
22          EXHAUST VALVE CH11022 12
23         INJECTOR R/CH11945 6
24         THERMOSTAT CH11620 2
25         TOP GASKET KIT  KRP1546 1
26         BOTTOM GASKET KIT KRP1547 1
27         Fuel Filter CH10931 1
28         Pre-Fule Filter CH10930 1
29         Oil Filter CH10929 1
30         FAN BELT CH11950 1
31         ALTERNATOR BELT CH11202 1
32         Air Filter  SEV551F/4 1
33         THERMOSTAT CH11620 2
34         VALVE SEAT INSERT CH10731 12
35         VALVE SEAT INSERT CH10732 12
36         SEAL - VALVE STEM CH11486 24
37         VALVE GUIDE CH10724 24
38         EXHAUST VALVE CH11022 12
39         INTAKE VALVE CH11021 12
40         VALVE COLLET CH10019 48
41         VALVE SPRING OUTER CH11487 24
42         VALVE SPRING INNER CH11489 24
43         SEAT CH10715 24
44         BIG END BEARING KIT KRP3016 1
45         PISTON KIT KRP3017 6
46         PISTON RING KIT KRP3018 6
47         CYLINDER LINER CH11180 6
48         BAND CH10673 6
49         SEAL - O RING CH10674 6
50         SEAL - O RING CH10677 6
51         SEAL - O RING CH11179 6
52         MAIN BEARING KIT KRP3118 1
53         THRUST WASHER KIT KRP3206 1
54         STARTER MOTOR CH12807 1
55         WATER PUMP KRP1715 1
56         ALTERNATOR CH11087 1
57         INJECTOR R/CH11945 6
58         TURBOCHARGER CH11946 1
59         GASKET - TURBOCHARGER CH11471 1
60         GASKET - CYLINDER HEAD KRP1529 1
61         SEAL - ROCKER BOX COVER CH11353 1
62         FRONT OIL SEAL CH11379 1
63         SEAL - REAR END OIL CH11304 1
64         SEAL - SUMP CH10887 1
65         LIFT PUMP KRP1679 1
66         OIL PUMP CH10860 1
67         TEMPERATURE SENSOR KRP1687 2
68         AIR PRESSURE SENSOR KIT KRP1692 1
69         OIL PRESSURE SENSOR KIT CH12006 1
70         TEMPERATURE SENSOR KRP1688 1
71         SPEED SENSOR CH12003 1
72         SPEED SENSOR KRP1705 1
73         CRANKSHAFT ASSEMBLY CH12792 1
74         CAMSHAFT CH11988 1
英国珀金斯Perkins柴油发动机2506C-E15TAG1原装进口零配件
BuildList: MGAF4070
序号 零件名称 零件号 数量(一车付)
1             Fuel Filter CH10931 1
2             Pre-Fule Filter CH10930 1
3             Oil Filter CH10929 1
4             Air Filter  SEV551F/4 1
5             ALTERNATOR BELT CH11202 1
6             FAN BELT CH11950 1
7             SEAL - ROCKER BOX COVER CH11353 1
8             GASKET - CYLINDER HEAD KRP1529 1
9             THERMOSTAT CH11620 2
10         FRONT OIL SEAL CH11379 1
11         SEAL - REAR END OIL CH11304 1
12         Fuel Filter CH10931 1
13         Pre-Fule Filter CH10930 1
14         Oil Filter CH10929 1
15         ALTERNATOR BELT CH11202 1
16         FAN BELT CH11950 1
17         Air Filter  SEV551F/4 1
18         SEAL - ROCKER BOX COVER CH11353 1
19         GASKET - CYLINDER HEAD KRP1529 1
20         PISTON RING KIT KRP3018 6
21         INTAKE  VALVE CH11021 12
22          EXHAUST VALVE CH11022 12
23         INJECTOR R/CH11945 6
24         THERMOSTAT CH11620 2
25         TOP GASKET KIT  KRP1546 1
26         BOTTOM GASKET KIT KRP1547 1
27         Fuel Filter CH10931 1
28         Pre-Fule Filter CH10930 1
29         Oil Filter CH10929 1
30         FAN BELT CH11950 1
31         ALTERNATOR BELT CH11202 1
32         Air Filter  SEV551F/4 1
33         THERMOSTAT CH11620 2
34         VALVE SEAT INSERT CH10731 12
35         VALVE SEAT INSERT CH10732 12
36         SEAL - VALVE STEM CH11486 24
37         VALVE GUIDE CH10724 24
38         EXHAUST VALVE CH11022 12
39         INTAKE VALVE CH11021 12
40         VALVE COLLET CH10019 48
41         VALVE SPRING OUTER CH11487 24
42         VALVE SPRING INNER CH11489 24
43         SEAT CH10715 24
44         BIG END BEARING KIT KRP3016 1
45         PISTON KIT KRP3017 6
46         PISTON RING KIT KRP3018 6
47         CYLINDER LINER CH11180 6
48         BAND CH10673 6
49         SEAL - O RING CH10674 6
50         SEAL - O RING CH10677 6
51         SEAL - O RING CH11179 6
52         MAIN BEARING KIT KRP3118 1
53         THRUST WASHER KIT KRP3206 1
54         STARTER MOTOR CH12405 1
55         WATER PUMP KRP1715 1
56         ALTERNATOR CH11087 1
57         INJECTOR R/CH11945 6
58         TURBOCHARGER CH11946 1
59         GASKET - TURBOCHARGER CH11471 1
60         GASKET - CYLINDER HEAD KRP1529 1
61         SEAL - ROCKER BOX COVER CH11353 1
62         FRONT OIL SEAL CH11379 1
63         SEAL - REAR END OIL CH11304 1
64         SEAL - SUMP CH10887 1
65         LIFT PUMP KRP1679 1
66         OIL PUMP CH10860 1
67         TEMPERATURE SENSOR KRP1687 2
68         AIR PRESSURE SENSOR KIT KRP1692 1
69         OIL PRESSURE SENSOR KIT CH12006 1
70         TEMPERATURE SENSOR KRP1688 1
71         SPEED SENSOR CH12003 1
72         SPEED SENSOR CH12004 1
73         CRANKSHAFT ASSEMBLY CH12792 1
74         CAMSHAFT CH11988 1

日兴动力科技建立了一套完整的英国珀金斯Perkins零配件供应体系,全天候快速供应,从而能够保证您的Perkins机器正常运转。珀金斯Perkins的备用零件的库存齐全,全部采用电脑化管理,随时满足的零件需要纯正珀金斯Perkins配件是您最佳的选择因为您所得到的是延长珀金斯Perkins机器寿命的最佳保证。

注意:网页中公布的Perkins发动机配件号与图片仅为参考,因 英国珀金斯Perkins柴油发动机/零配件型号与技术参数太多,没能全部展示,如有零配件与维修技术方面的需求,请与本司的在线客服人员沟通与交流,希望我们能够帮您节约更多等待备件到达的时间和维修技术方面的困难。
